The DipoleGraph(n) function creates the order n dipole graph, a multigraph with two vertices and n edges between them.

The order n dipole graph is the plane dual of the cycle graph on n vertices.

$\mathrm{with}\left(\mathrm{GraphTheory}\right)\:$

$\mathrm{with}\left(\mathrm{SpecialGraphs}\right)\:$

$\mathrm{DG}≔\mathrm{DipoleGraph}\left(5\right)$

$\mathrm{DG}≔\mathrm{Graph\; 1:\; an\; undirected\; multigraph\; with\; 2\; vertices\; and\; 5\; edges}$

$\mathrm{Edges}\left(\mathrm{DG}\right)$

$\left[\left\{1\,2\right\}\,\left\{1\,2\right\}\,\left\{1\,2\right\}\,\left\{1\,2\right\}\,\left\{1\,2\right\}\right]$

$\mathrm{DrawGraph}\left(\mathrm{DG}\right)$

$\mathrm{PlaneDual}\left(\mathrm{CycleGraph}\left(5\right)\,\mathrm{multigraph}\right)$

$\mathrm{Graph\; 2:\; an\; undirected\; multigraph\; with\; 2\; vertices\; and\; 5\; edges}$

The GraphTheory[SpecialGraphs][DipoleGraph] command was introduced in Maple 2023.

For more information on Maple 2023 changes, see Updates in Maple 2023.
